Opis
Technically permissible total weight: | 25000 | [kg] |
Permissible total weight: | 23000 | [kg] |
Load capacity: | 15300 | [kg] |
Empty weight: | 7700 | [kg] |
Load volume: | 28 | [m 3] |
Unloading efficiency: | 200-400 | [t/h] |
Loading case inside lenght: | 6015 | [mm] |
Loading case inside width: | 2492 | [mm] |
Dimensions (Lenght/Width/Height) | 9142/2900/3645 | [mm] |
Sidewall height: | 1440+340 | [mm] |
Thickness of floor/sidewalls/extensions: | 4/4/3 | [mm] |
Distance from base to the platform: | 3400 | [mm] |
Wheel track: | 2200 | [mm] |
Suspension: | Tandem on parabolic springs with passively steered rear axle | |
Hitch-ring load: | 3000 | [kg] |
Tyres: | 700/50-26,5 | |
Maximum speed: | 40 | [km/h] |
Tractor power requirement: | 165/121,3 | [hp/kW] |
Hydraulically folded conveyor: | – | |
Diameter: | 430 | [mm] |
Lenght: | 5170 | [mm] |
PTO shaft speed | 1000 | rpm |
Height of the edge of unloading port: | 4550-4850 | [mm] |
Standard equipment
Monocoques loading case with additional vertical stiffeners and screwed sidewall extensions
Floor with double – auger grain carts
Two-segment front conveyor hydraulically folded with hydraulic safety lock
Double segmented hydraulically folded auger
Double floor conveyor with two-stage controller of floor conveyor speed
Three windows to control the level of loaded material
Hydraulically driven revision hole for load-carrying body cleaning
Canvas frame
Operator’s platform on rear side
A ladders facilitating access to the loading case
Tandem type suspension with 4 parabolic springs and wheel track 1810mm, rear axle passively steered
Rear axel hydraulic blocking system when driving backwards
Braking system: single or double line pneumatic or hydraulic
Axles for 60 km/h with drum brakes Ø406×140
Crank hand brake
Drawbar: fixed integrated with frame to connect with upper o lower hitch to a tractor
Drawbar support: telescopic supporting leg with 2-sectional gearing mechanism
Drawbar towing hitch: rotary towing eye Ø50mm
Sidewalls profiles with addictional supports and extensions 340mm
PTO shaft with overload clutch with tractor 1 3/4″ Z=20 ending
A set of steel mudguards
Double-component chemically hardened painting materials
Wheel chocks and racks
12V LED lighting system
Frame painting colour: red RAL3000 PRONAR
Loading case painting colour: green RAL6010 PRONAR
