Technical data |
Technically permissible total weight: |
13000 |
[kg] |
Permissible total weight: |
12000 |
[kg] |
Load capacity: |
8700 |
[kg] |
Empty weight: |
3300 |
[kg] |
Loading space: |
17,4 |
[m 2] |
Loading platform length: |
7170 |
[mm] |
Loading platform width (with edges/without edges): |
2517/2410* |
[mm] |
Dimensions: length/width/height: |
9290/2550/2740 |
[mm] |
Loading platform height: |
1680 |
[mm] |
Platform thickness: |
4 |
[mm] |
Platform height, measured from the ground: |
1060 |
[mm] |
Wheel track: |
1820 |
[mm] |
Suspension: |
parabolic springs |
Hitch-ring load: |
1925 |
[kg] |
Tyres: |
15.0/70-18 |
Maximum speed: |
40 |
[km/h] |
Tractor power requirement: |
62,5/45,9 |
[hp/kW] |
|
* width of the loading case suitable for EUROPALET transport |
|
|
|
|
Standard equipment |
|
Rounded profiles on the floor edges |
Reinforced platform – 4mm |
Frame: rectangular made of closed profiles |
Tandem suspenssion on 4 parabolic springs with 1215 mm axle track with fixed axles with drum brakes |
Chassis frame adjusted to the rear hitch mounting |
Drawbar type: uniwersal rigid to couple with lower or upper hitch of the tractor |
Drawbar towing hitch: rotary with towing eye ∅50 mm |
Drawbar support: hydraulic supporting leg (scissor) |
Side ladders with rounded profiles |
Holes for belt tightening |
Holes for belt tightening on the side ladders |
Braking system: single or double line air or hydraulic |
Crank hand brake |
12V lightning system with rear electric socket |
Commercial road lighting system with side lights |
Rear underrun protection with integrated commercial road lighting system (according to 70/221/EW) |
Double-component chemically hardened painting materials |
Wheel chocks and racks |
Platform colour: green RAL6010 PRONAR |
