Technical data |
Technically permissible total weight: |
19000 |
[kg] |
Permissible total weight: |
18000 |
[kg] |
Load capacity: |
13720 |
[kg] |
Empty weight: |
4280 |
[kg] |
Loading space: |
24 (26,2*) |
[m 2] |
Loading platform length: |
9695 |
[mm] |
Loading space length: |
9880 (10770*) |
[mm] |
Loading platform width: |
2435** |
[mm] |
Dimensions: length /width/height: |
11995***/2500/2860 |
[mm] |
Loading platform height: |
1680 |
[mm] |
Platform thickness: |
3 |
[mm] |
Platform height, measured from the ground: |
1180 |
[mm] |
Wheel track: |
1820 |
[mm] |
Suspension: |
parabolic springs |
Tyres: |
500/50-17 |
Maximum speed: |
40 |
[km/h] |
Tractor power requirement: |
93,6/68,8 |
[hp/kW] |
|
* With pulled out rear frame exending the platform length |
** EURO pallets transportation widht |
*** Standard platform length |
|
Standard equipment |
|
Loading platform with flat floor edges |
Frame made of open rectangular closed profiles |
Drawbar type: V- type rigid with towing eye ø40 mm |
Steering: rotating turntable |
Side ladders with rounded profiles |
Platform extension |
Braking system: single line, double line air or hydraulic |
Crank hand brake |
12V lightning system with rear electric socket with clearance lights |
Double-component chemically hardened painting materials, UV-resistant |
Rear underrun protection according to 70/221/EC integrated with commercial road lighting system |
Rear electric socket |
Wheel chocks + racks (2 pcs.) |
Wheel chocks hidden in galvanized pockets |
Platform color: green RAL6010 PRONAR |
