| Technical data |
|
Version WITHOUT hydr. Side walls |
Version WITH hydr. side walls |
|
| Permissible total weight: |
24000 |
[kg] |
| Load capacity: |
17420 |
15870 |
[kg] |
| Empty weight: |
6580 |
8130 |
[kg] |
| Loading space (rear frame folded/extended): |
28,8/31,4 |
28,8 (folded only) |
[m 2] |
| Loading platform length (rear frame folded/extended): |
12000/13100 |
12000 (folded only) |
[mm] |
| Loading platform width: |
2470 |
2470 |
[mm] |
| Dimensions: length/width/height: |
14100/2525/2900 * |
14100/2545/3715 *** |
[mm] |
| 15200/2525/2900 ** |
14100/2945/4585 **** |
[mm] |
| Ladders height measured from the platform: |
1790 |
2605 |
[mm] |
| Hydraulic side walls heigh: |
– |
2425 |
[mm] |
| Platform height, measured from the ground: |
1110 |
[mm] |
| Platform thickness: |
3 |
[mm] |
| Wheel track: |
1960 |
[mm] |
| Suspension: |
parabolic springs |
| Tyres: |
445/45R19,5 |
| Maximum speed: |
40 |
[km/h] |
| Tractor power requirement: |
124,8/91,8 |
[HP/kW] |
|
|
|
|
| * rear frame folded with rear ladder 14° |
| ** rear frame extended with rear ladder 14 ° |
| *** side walls with transport position |
| **** side walls with working position lifted to height 3000 mm above the floor |
|
|
|
|
| Standard equipment |
| Platform with profiles on the floor edges |
| Frame made of I-beams, open and closed rectangular profiles |
| Frame adjusted to the rear hitch mounting |
| Frame adjusted for mounting hydraulic sidewalls |
| Drawbar type: V- type rigid with towing eye ø40 mm |
| Steering: rotating turntable |
| Side ladders with adjustment of angle inclination suitable for transportaion round and square bales |
| Extendable rear frame with ladder increasing the loading space |
| Extendable rear frame supported by pin retainer |
| Holes for belt tightening on the platform side |
| Braking system: single line air or hydraulic |
| Crank hand brake |
| 12V lightning system with rear electric socket and clearance lights |
| Rear underrun protection according to 70/221/EWG with lights and space for number plate |
| Rear electric socket |
| Wheel chocks and racks |
| Double-component chemically hardened painting materials, UV-resistant |
| Platform color: green RAL6010 PRONAR |
| Wheel chocks in galvanized pockets |
