Technical data |
Permissible total weight: |
8200 |
[kg] |
Load capacity: |
6000 |
[kg] |
Empty weight: |
2200 |
[kg] |
Load volume: |
4.1 |
[m 3] |
Loading space: |
7.6 |
[m 2] |
Internal lenght of loading space: |
4000 |
[mm] |
Internal width of loading space: |
1900 |
[mm] |
Dimensions: length/width/height: |
5780/2230/2750 |
[mm] |
Sidewall height: |
600 |
[mm] |
Floor/wall thickness: |
3 / 2,5 |
[mm] |
Platform height, measured from the ground: |
1150 |
[mm] |
Wheel track: |
1660 |
[mm] |
Suspension: |
Single axle, fixed |
Hitch-ring load: |
1500 |
[kg] |
Tyres: |
500/50-17 |
Construction speed: |
25 |
[km/h] |
PTO speed: |
68/50 |
[hp/kW] |
Minimum tractor power requirement / adaptor type: |
540 |
[rpm] |
Adapter type / max spreading width: |
AH21 / 2.4 |
[ – /m] |
|
Standard equipment |
|
Universal loading case |
Suspension: fixed single axle |
AH21 adapter with 2 horizontal beaters |
Chain conveyor with two 11mm chains of high quality steel, with hydraulic drive and stepless speed regulation |
Drawbar type: fixed to couple with lower hitch of the tractor |
Drawbar towing hitch: rotary with towing eye ø50mm |
Drawbar support: straight with folded steel wheel |
Control from tractor’s hydraulic distributor (fluent speed adjustment) |
Braking system: double line air or hydraulic |
Crank hand brake |
Lighting system 12V |
Wheel chocks + racks (2 pcs.) |
Front protective mesh |
PTO shaft- standard Z6 with an overload clutch |
Chemically hardened two-component painting materials , UV-resistant. |
Colour green RAL6010 PRONAR |
