Allowable total weight (technically): | 15000 | [kg] |
Permissible total weight: | 15000 | [kg] |
Load capacity: | 12130 * | [kg] |
Empty weight: | 2870 | [kg] |
Lenght without a container: | 5940 | [mm] |
Lenght with the shortest/longest container: | 6415/6782 | [mm] |
Width without a container: | 2360 | [mm] |
Width with a container (min/max): | 2360/2550 | [mm] |
Attachement dimensions of the container: | ||
Hook height: (min/max): | 1450/1570 | [mm] |
Rolls track: | 1070 | [mm] |
Permissible dimensions of the container: | ||
Lenght: (min/max): | 4100 – 5050 | [mm] |
Width: | max 2550 | [mm] |
Height: | max 2000 | [mm] |
Height of the trailer without container: | 2512 | [mm] |
Height of the guide rollers from the ground | 900 | [mm] |
Container maximum tipping angle/oil requirement/oil pressure | 46/15/200 | [˚/l/bar] |
Wheel track: | 1830 | [mm] |
Suspension: | tandem with trailing arm | |
Hitch-ring load: | 2000 | [kg] |
Tyres: | 500/50-17 | |
Construction speed: | 40 | [km/h] |
Tractor power requirement: | 78/57.3 | [hp/kW] |
* with the weight of the container with recommended lengh, it might be neccesary to move the container backwards while preparing for tipping |
Standard equipment
Tipping frame: rectangular made of closed profiles
Tandem suspension with 2 trailing arms and fixed axle shafts equiped in drum brakes 300×135
Drawbar: rigid to couple with lower hitch of the tractor (transport hitch, piton fix)
Drawbar towing hitch: rotary towing eye Ø50 (hitch, piton fix)
Drawbar support: hydraulic straight leg with cut-off valve (it needs permanent or occasional connection with the tractor by single hydraulic line)
Crank hand brake
Hydraulic blocking system of the trailing arm (suspension)
Braking system: double or single line pneumatic or hydraulic
Rear bumper with manual setting in 2 positions (depends on length of the container)
Lighting system 12 V without side clearence lights
Rear lamps with protective grating
Steel mudguards over the wheels
Wheel chocks + racks
Hydraulic reloading system with manual switch winch / tipper
Trailer requires a tractor with three pairs of hydraulic outputs (control of suspension lock, pivoting frame and hook frame)
Chemically hardened two-component painting materials , UV-resistant.
Tipping frame colour: red RAL3000 PRONAR
