Opis
| Permissible total weight: | 11000 | [kg] |
| Load capacity: | 8385 | [kg] |
| Empty weight: | 2615 | [kg] |
| Load volume: | 6.4 | [m 3] |
| Loading space: | 9.7 | [m 2] |
| Loading case inside length: | 4000 | [mm] |
| Loading case inside width: | 2420 | [mm] |
| Dimensions: length/width/height: | 5674/2550/1740 | [mm] |
| Sidewall height: | 650 | [mm] |
| Floor/wall thickness: | 4/4 | [mm] |
| Front wall/ rear wall thickness: | 4/4 | [mm] |
| Platform height, measured from the ground: | 1050 | [mm] |
| Wheel track: | 1990 | [mm] |
| Suspension: | tandem with trailing arm | |
| Hitch-ring load: | 1500 | [kg] |
| Tyres: | 400/60-15.5 | |
| Maximum speed: | 40 | [km/h] |
| Tipping system: | 1-side | |
| Tipping cylinder (piston stroke/oil requirement/working pressure): | 1700mm/13L/200bar | |
| Tractor power requirement: | 62.6/46 | [hp/kW] |
| Tipping angle (backwards): | 50 | [˚] |
Standard equipment
Very strong construction (monocoque type) of loading case with vertical ribs reinforcing the sidewalls, side wall and floor made of one piece of steel, 90° angle between floor and wall
Fastening hooks inside the loading box for securing the load – 4 hooks
Hydraulically driven rear flap with height 325 mm, opened downwords
Chassis frame made of hight strength steel with rectangular closed profiles
Tandem suspension with 2 trailing arms with 1120 mm wheelbase with fixed axles shafts equipped in drum brakes 300×90
Drawbar type: universal rigid to couple with lower or upper hitch of the tractor, with a ladder and platform
Drawbar hitch: rotary with Ø50 towing eye
Drawbar support: telescopic supporting leg with fixed parking foot
“Braking system: hydraulic
”
Crank hand brake
Wheel chocks + racks (2pcs)
12 V lighting system with rear electric socket, LED lamps, with airtight connection, with side clearence lights
Rear lamps with protective grating
Tipping system: hydrauilc with automatic cut-off valve and thick safety steel cables
Ladder and steps facilitating the access to the loading case
Mechanical support of the loading case
Hydraulic cables holder with a support for tractor connectors
Double-component chemically hardened painting materials, UV-resistant
Tipping frame colour: red RAL3000 PRONAR
Side walls painting colour: yellow RAL1007
