Technical data |
Technically permissible total weight: |
16000 |
[kg] |
Permissible total weight: |
15000 |
[kg] |
Load capacity: |
11300 |
[kg] |
Empty weight: |
3700 |
[kg] |
Loading space: |
24 (26,2*) |
[m 2] |
Loading platform length: |
9695 |
[mm] |
Loading space length: |
9880 (10770*) |
[mm] |
Loading platform width: |
2435** |
[mm] |
Dimensions: length/width/height: |
11995***/2500/2780 |
[mm] |
Loading platform height: |
1680 |
[mm] |
Platform thickness: |
3 |
[mm] |
Platform height, measured from the ground: |
1100 |
[mm] |
Wheel track: |
1730 |
[mm] |
Suspension: |
parabolic springs |
Tyres: |
400/60-15.5 |
Maximum speed: |
40 |
[km/h] |
Tractor power requirement: |
83,2/61 |
[hp/kW] |
|
* With pulled out rear frame exending the platform length |
** EURO pallets transportation widht |
*** Standard platform length |
|
Standard equipment |
|
Flat profiles on the floor edges |
Frame: rectangular made of closed profiles |
Drawbar: V type with ø40 mm fixed towing eye |
Steering: rotating turntable |
Side ladders: front and rear |
Regulated rear frame |
Braking system: single or double line air or hydraulic |
Crank hand brake |
Double-component chemically hardened painting materials |
12V lightning system with clearance lights and rear electric socket |
Rear underrun protection with integrated commercial road lighting system (according to 70/221/EW) |
Wheel chocks and racks |
Platform colour: green RAL6010 PRONAR |
Rear electric socket |
