Opis
Allowable total weight (constructional): | 13000 | [kg] |
Allowable total weight: | 13000 | [kg] |
Loading capacity: | 8000 | [kg] |
Empty weight: | ok. 5000* | [kg] |
Load volume: | 17,4 | [m 3] |
Loading platform length: | 7170 | [mm] |
Loading platform width: | 2435* | [mm] |
Dimensions: length/width/height: | 9290/3680/2955 | [mm] |
Loading platform height: | 1680 | [mm] |
Floor thickness: | 3 | [mm] |
Platform height, measured from the ground: | 1310 | [mm] |
Track spacing | 2270 | [mm] |
Track width | 1400 | [mm] |
Track length | 4040 | [mm] |
Suspension: | rigid swingarm | |
Hitch-ring load: | 1925 | [kg] |
* Indicative curb weight, the actual weight depends on the construction of tracks and equipment |
Standard equipment
Loading platform with flat side borders
Chassis frame made of closed rectangular profiles
Drawbar type: uniwersal rigid to couple with lower or upper hitch of the tractor
Drawbar towing hitch: rotary with towing eye ∅50 mm
Drawbar support: hydraulic scissor-type leg
Side ladders: front and rear
Lighting system 12V with clearence lights
Rear under-ride guard according to 70/221/EC integrated with commercial road lighting system
Rear electric socket
Chemically hardened painting materials , UV-resistant
Platform color: green RAL6010 PRONAR
