Technical data |
|
Version WITHOUT hydr. Side walls |
Version WITH hydr. side walls |
|
Permissible total weight: |
18000 |
[kg] |
Load capacity: |
13470 |
12160 |
[kg] |
Empty weight: |
4530* |
5840 |
[kg] |
Loading space (rear frame folded/extended): |
24/26,2 |
23,8 (folded only) |
[m 2] |
Loading platform length (rear frame folded/extended): |
9880/10770 |
9695 (folded only) |
[mm] |
Loading platform width: |
2517 |
[mm] |
Dimensions: length/width/height: |
12000/2550/2860 ** |
12000/2545/3715 **** |
[mm] |
13200/2555/2860 *** |
12000/2945/4585 ***** |
[mm] |
Ladders height measured from the platform: |
1680 |
2605 |
[mm] |
Hydraulic side walls heigh: |
– |
2425 |
[mm] |
Platform height, measured from the ground: |
1110 |
[mm] |
Platform thickness: |
4 |
[mm] |
Wheel track: |
1820 |
[mm] |
Suspension: |
parabolic springs |
Tyres: |
500/50-17 |
Maximum speed: |
40 |
[km/h] |
Tractor power requirement: |
93,6/68,8 |
[HP/kW] |
|
|
|
|
* Weight of the trailer equipped with front and rear posts instead of front and rear ladders – 4802 kg- |
** rear frame extended with rear ladder 1 ° |
*** rear frame extended with rear ladder 14° |
**** side walls with transport position |
***** siede walls with working position lifted to height 3000 mm above the floor |
|
|
|
|
Standard equipment |
Rounded profiles on the floor edges |
Reinforced platform floor equipped with holes for posts assembly at the front, rear and side of the trailer |
Frame made of open and closed rectangular profiles |
Frame adjusted to the hydraulic walls mounting |
Frame adjusted to the rear hitch mounting |
Drawbar type: V- type rigid with towing eye ø40 mm |
Steering: rotating turntable |
Side ladders with rounded profiles |
Platform extension |
Holes for belt tightening on the platform side |
Holes for belt tightening on the side ladders |
Braking system: single line, double line air or hydraulic |
Crank hand brake |
12V lightning system with rear electric socket and clearance lights |
Rear underrun protection according to 70/221/EWG with lights and space for number plate |
Rear electric socket |
Double-component chemically hardened painting materials, UV-resistant |
Platform color: green RAL6010 PRONAR |
Wheel chocks in galvanized pockets |
