Technical data |
|
Version WITHOUT hydr. Side walls |
Version WITH hydr. side walls |
|
Permissible total weight: |
24000 |
[kg] |
Load capacity: |
18200 |
16900 |
[kg] |
Empty weight: |
5500 |
6950 |
[kg] |
Loading space (rear frame folded/extended): |
23,8/26,4 |
23,8 (folded only) |
[m 2] |
Loading platform length (rear frame folded/extended): |
9900/1100 |
9900 (folded only) |
[mm] |
Loading platform width: |
2470 |
2470 |
[mm] |
Dimensions: length/width/height: |
12000/2525/2900 * |
12000/2545/3715 *** |
[mm] |
13100/2525/2900 ** |
12000/2945/4585 **** |
[mm] |
Ladders height measured from the platform: |
1790 |
2605 |
[mm] |
Hydraulic side walls heigh: |
– |
2425 |
[mm] |
Platform height, measured from the ground: |
1110 |
[mm] |
Platform thickness: |
3 |
[mm] |
Wheel track: |
1960 |
[mm] |
Suspension: |
parabolic springs |
Tyres: |
445/45R19,5 |
Maximum speed: |
40 |
[km/h] |
Tractor power requirement: |
124,8/91,8 |
[HP/kW] |
|
|
|
|
* rear frame folded with rear ladder 14° |
** rear frame extended with rear ladder 14 ° |
*** side walls with transport position |
**** siede walls with working position lifted to height 3000 mm above the floor |
|
|
|
|
Standard equipment |
Platform with profiles on the floor edges |
Reinforced platform floor equipped with sockets for stanchions |
Frame made of I-beams, open and closed rectangular profiles |
Frame adjusted to the rear hitch mounting |
Frame adjusted for mounting hydraulic sidewalls |
Drawbar type: V- type rigid with towing eye ø40 mm |
Steering: rotating turntable |
Side ladders with adjustment of angle inclination suitable for transportaion round and square bales |
Extendable rear frame with ladder increasing the loading space |
Extendable rear frame supported by pin retainer |
Holes for belt tightening on the platform side |
Braking system: single line air or hydraulic |
Crank hand brake |
12V lightning system with rear electric socket and clearance lights |
Rear underrun protection according to 70/221/EWG with lights and space for number plate |
Rear electric socket |
Wheel chocks and racks |
Double-component chemically hardened painting materials, UV-resistant |
Platform color: green RAL6010 PRONAR |
Wheel chocks in galvanized pockets |
