Additional equipment (optional) |
Drawbar hitch: fixed with Ø40mm towing eye in accordance to DIN11026 to couple with upper hitch of the tractor |
Drawbar hitch: fixed ball-type K80mm to couple with lower hitch of the tractor |
Design and build with 3 tones hitch ring load, fixed to couple with lower or upper hitch of the tractor, amortised with steel spring and with telescopic drawbar support with a gear |
Passively steered rear axle with hydraulic turning blockade |
Braking system: double line air with automatic (ALB) |
Rear sockets for hydraulic installation and brakes for second trailer |
Rear underrun protection homologated according to directive WE type, foldable |
Rear grain chute |
Sidewall extensions height 580mm made of steel 2mm thickness and front wall extansion made of wire mesh 30×30 window, with steel blanking plate, with stabilizing bar |
Sidewall extensions height 1000mm (instead of 580mm) increasing load volume up to 27,7m3, made of steel 2mm thickness and folded front wall extansion made of wire mesh 30×30 window, with stabilizing bar |
Rear automatic hitch UNIMAR |
Rear automatic hitch RO*400A4600 |
Operator’s platform for side walls extensions with height 580mm |
Rolled canvas cover with a frame for walls extensions with height 580mm |
Front mudguards |
Side underrun protection |
Tool box |
Tyres 385/65 R22.5 (15R22.5) |
Tyres 425/65 R22.5 (16.5R22.5) |
Tyres 445/65 R22.5 (18R22.5) |
Tyres 500/60-22,5 |
Tyres 500/60 R22.5 |
Tyres 550/60-22.5 |
Tyres 560/60 R22.5 |
Tyres 600/50-22.5 – the width of the trailer exceeds 2550mm |
Tyres 600/50R22.5 – the width of the trailer exceeds 2550mm |
Tyres 600/55-22.5 – the width of the trailer exceeds 2550mm |
Tyres 600/55R22.5 – the width of the trailer exceeds 2550mm |
Spare wheel (separately) 385/65 R22.5 (15 R22.5) Regenerated |
Spare wheel (separately) 385/65 R22.5 (15 R22.5) |
Spare wheel (separately) 425/65 R22.5: |
Spare wheel (separately) 445/65 R22.5: |
Spare wheel (separately) 500/60 R22.5: |
Spare wheel (separately) 550/60-22.5: |
Spare wheel (separately) 500/60-22,5 |
Spare wheel (separately) 560/60 R22.5: |
Spare wheel (separately) 600/55-22.5: |
Spare wheel (separately) 600/50-22.5: |
Spare wheel (separately) 600/50 R22.5: |
Warning triangle |
Shock absorber for falling potatoes – two sets of rubber belts, 2,3m of length each, mounted on the sidewall extensions (side extensions necessaary) |
Non standard colours according to RAL CALSSIC codes * |
|
* doesn’t aply for units on stock |
